XYZ AURORAX 50

Exceptional value and efficiency-design in panoramic view

The XYZ AURORAX 50 redefines performance and style with its panoramic tempered glass design, optimized airflow structure, and next-generation connectivity. Designed for ATX, M-ATX, and ITX motherboards, it combines elegance, cooling performance, and functionality in a modern, compact format.

Equipped with three AIRPULSE 100 fans and support for liquid cooling systems, the AURORAX 50 delivers excellent thermal performance—perfect for high-end gaming rigs and professional setups.

• Panoramic Tempered Glass Design
Sleek side panel with tool-free side clip system for easy access and a clear view of all internal components.
• High-Efficiency Airflow
Its optimized internal structure and three AIRPULSE 100 A-RGB PWM 120 mm fans provide consistent, silent cooling through hydraulic bearing technology.
• Next-Generation Connectivity
Equipped with 2x USB 3.0 and 1x Type-C Gen 2 ports for seamless connection with the latest peripherals and devices.
• Ample Compatibility and Internal Space
Supports GPUs up to 395 mm, CPU coolers up to 185 mm, and ATX PSUs up to 200 mm, ensuring flexible configuration options for high-performance builds.
• Total Control of Lighting and Cooling
Integrated PWM CHAIN LINK controller for synchronized fan speed and A-RGB lighting management, compatible with most major motherboard software.

SKU | X-CS-AURORAX-50-B
EAN | 6978262012014

Variation

BLACK WHITE
VIEW SPECIFICATIONS FIND RETAILER

Panoramic Tempered Glass Design

Sleek side panel with tool-free side clip system for easy access and a clear view of all internal components.

High-Efficiency Airflow

Its optimized internal structure and three AIRPULSE 100 A-RGB PWM 120 mm fans provide consistent, silent cooling through hydraulic bearing technology. Compatible with AIO up to 360mm in TOP.

3x AIRPULSE 100 A-RGB Fans Included

Three 120 mm front fans and one 120 mm rear fan with hydraulic bearings and addressable LEDs deliver balanced airflow at a low noise level of just 25.3 dBA.

Ample Compatibility and Internal Space

Supports GPUs up to 395 mm, CPU coolers up to 185 mm, and ATX PSUs up to 200 mm, ensuring flexible configuration options for high-performance builds.

Next-Generation Connectivity

Equipped with 2x USB 3.0 and 1x Type-C Gen 2 ports for seamless connection with the latest peripherals and devices.

Technical Specifications

XYZ AURORAX 50

Model Name: XYZ AURORAX 50
Structure Dimensions: 430 × 230 × 436 mm
Total Dimensions: 435 × 230 × 456 mm
Box Size: 525 × 290 × 510 mm
Material: Steel, Tempered Glass, Mesh
Steel Thickness: SPCC 0.5 mm (0.6 mm outer / 0.5 mm inner)
Color: Black
Net Weight: 6 kg
Gross Weight: 8 kg
Motherboard Compatibility: ATX / M-ATX / ITX / E-ATX
MB BTF Support: No
MB Rubber Accessories: 2
Cable Velcro XYZ Organizer: Yes

Pre-installed Fans:
Front: 2 x 120 mm (AIRPULSE 100  A-RGB PWM, reversed)
Rear: 1 x 120 mm (AIRPULSE 100  A-RGB PWM, regular)

Supported Fan Layout:
Front: 2 x 120 mm (MBO Bracket)
Top: 3 x 120 mm / 2 x 140 mm
Rear: 1 x 120 mm / 1 x 140 mm

Controller: PWM CHAIN LINK
Radiator Support:
Top: 1 x 360 mm
Rear: 1 x 120 mm

Drive Bays: 1 or 2 x 3.5” / 2 x 2.5”
Power Supply: Standard ATX
Expansion Slots: 7

2 x USB 3.0
1 x Type-C Gen 2
1 x HD Audio In/Out
1 x Reset / 1 x LED Change Button

Max GPU Length: 395 mm
Max CPU Cooler Height: 185 mm
Max PSU Size: 200 mm

Available Colors
Black: X-CS-AURORAX-50-B
White: X-CS-AURORAX-50-W

AIRPULSE 100 A-RGB Fan Specifications

Dimensions: 120 x 120 x 25 mm
Rated Voltage: DC 12V
Rated Current: 141 mA ±10%
Operating Voltage: DC 5–13.8V
Start-up Voltage: ≥5V
Speed: 1100 RPM ±10%
Power Consumption: 1.6W
Bearing Type: Hydraulic
Airflow: 32.5 CFM
Air Pressure: 1.10 mmH₂O
Noise Level: 25.3 dBA
MTTF: ≥40,000 hours (at 25 °C)

Download

Download Resources
